Compressor

Introduction

Products

undefined

Automotive A/C controller adapted to 5kW 800V platform.

As new energy has higher and higher requirements for battery life, the car battery voltage platform has also increased from the original 400V to the 800V platform, and the original 400V air conditioner compressor control system also needs to be upgraded. The new generation of electric vehicles requires higher voltage air conditioner compressors and controllers.



Silicon Carbide Empowers A New Generation Of On-Board Power Systems

In high-power application scenarios such as on-board charging system, traditional silicon-based power devices have shown their limitations. Sanan IC’s Silicon Carbide power devices have superior high-voltage and high-current working capability, which enables them to cope with more challenging power supply applications.


Up to

30%

Lower Losses

Up to

50%

Smaller Size

Up to

10%

Lower System Cost

Products

Power Electronics(5)

Part Number
Type
Voltage (V)
IF (A)
Generation
VF@Tj=25℃ (V)
VF@Tj=175℃ (V)
IFSM@Tc=25℃ (A)
IR max@Tj=25℃ (uA)
Tj(℃)
Package
Qualification

ADS065J004C2

SBD 650 4 @Tc=156℃ Gen-2 1.4 1.8 34 15 -55~175 TO220-2 汽车级

ADS065J020C2

SBD 650 20 @Tc=152℃ Gen-2 1.4 1.6 180 50 -55~175 TO220-2 汽车级

ADS065J040G2

SBD 650 20/40 @Tc=144℃ Gen-2 1.4 1.6 180* 50 -55~175 TO247-3 汽车级

ADS120J020H2

SBD 1200 20 @Tc=149℃ Gen-2 1.45 2.2 180 50 -55~175 TO247-2 汽车级

ADS120J040G2

SBD 1200 20/40 @Tc=142℃ Gen-2 1.45 2.2 180* 50 -55~175 TO247-3 汽车级
