With the continuous development of application scenarios and the continuous improvement of end users' requirements for link speed, active optical cable (AOC) will become the main form of consumer electronics interconnection and ultra-broadband interconnection. Sanan's integrated optical communication product portfolio can not only be used for long-distance and metro core networks, FTTx access and data centers, but also can be used to support optical networks connecting from households to personal smart terminals, realizing the final "optical advance and copper retreat" of the Internet.
Part Number
|
Chip Type |
Wavelength (nm) |
Rate (Gb/s) |
Surface(um) |
Shape |
Material |
Application |
---|---|---|---|---|---|---|---|
S-11ACPD08-G |
MPD | 1310/1550 | NA | 48400 | Singlet | InGaAs/InP | TOSA背光探测 |
S-12ACPD08-G |
MPD | 1310/1550 | NA | 48400 | Singlet | InGaAs/InP | TOSA背光探测 |
S-16ACPD15-G |
MPD | 1310/1550 | NA | 300 | Singlet | InGaAs/InP | TOSA背光探测 |
S-14AEPD01-G |
Edge MPD | 1310/1550 | NA | 40000 | Singlet | InGaAs/InP | TOSA背光探测 |
S-12AEPD08-G |
Edge MPD | 1310/1550 | NA | 40000 | Singlet | InGaAs/InP | TOSA背光探测 |
S-10ECPD10-G |
PD | 850/1270 | 8G | 35 | Singlet | InGaAs/InP | 彩光PD |
S-14BMPD08-G |
PD | 1310/1550 | 10~12G | 45 | Singlet | InGaAs/InP | 10G LR |
S-14BCPD25-G |
PD | 1310/1550 | 25G | 16 | Singlet | InGaAs/InP | |
S-15DMPD11-G |
PD | 1310/1550 | 25G | 20 | Singlet | InGaAs/InP | 25G LR |
S-41GMPD20-G |
PD | 1310/1550 | 4*25G | 20 | 250pitch array | InGaAs/InP | 100G PSM\CWDM |
S-15ACPD25-G |
PD | 1310/1550 | 25G | 32 | Singlet | InGaAs/InP | 25G LR |
S-41ACPD25-G |
PD | 1310/1550 | 4*25G | 32 | Array | InGaAs/InP | 100G LR |
S-10BGPD10-G |
PD | 850 | 10~14G | 60 | Singlet | GaAs/GaAs | 10G SR |
S-40BGPD10-G |
PD | 850 | 4*10~14G | 60 | Singlet | GaAs/GaAs | 10G SR |
S-10DGPD10-G |
PD | 850 | 10~14G | 60 | Singlet | GaAs/GaAs | 10G SR |
S-13BGPD19-G |
PD | 850 | 10~14G | 60 | Singlet | GaAs/GaAs | 10G SR |
S-39BGPD19-G |
PD | 850 | 4*10/14G | 60 | 250pitch 4-array | GaAs/GaAs | 40G SR |
S-118GPD19-G |
PD | 850 | 12*10G | 60 | |||
S-13AGPD19-G |
PD | 850 | 10~14G | 60 | Singlet | GaAs/GaAs | 10G SR |
S-39AGPD19-G |
PD | 850 | 4*10/14G | 60 | 250pitch 4-array | GaAs/GaAs | 40G SR |
S-10AGPD25-G |
PD | 850 | 25G | 30 | Singlet | GaAs/GaAs | 25~100G SR |
S-40AGPD25-G |
PD | 850 | 4*25G | 40 | GaAs/GaAs | ||
S-15AGPD25-G |
PD | 850 | 25/28G | 30 | 250pitch 3-array | GaAs/GaAs | 25G SR |
S-41AGPD25-G |
PD | 850 | 4*25/28G | 30 | 250pitch 4-array | GaAs/GaAs | 100~200G SR |
S-VS10SD1-001 |
VCSEL | 850 | 10~14G | 0 | TB Single | InGaAs/GaAs | 10G SR |
S-VS10FD1-001 |
VCSEL | 850 | 4*10/14G | 0 | TB 250pitch 4-array | GaAs/GaAs | 40G SR |
S-VS10ST1-001 |
VCSEL | 850 | 10~14G | 0 | TT Singlet | GaAs/GaAs | 10G SR |
S-VS10FT1-001 |
VCSEL | 850 | 4*10/14G | 0 | TT 250pitch 4-array | GaAs/GaAs | 40G SR |
S-VS10ST1-000 |
VCSEL | 850 | 10~14G | 0 | TT Singlet | GaAs/GaAs | 10G SR |
S-VS10FT1-000 |
VCSEL | 850 | 4*10/14G | 0 | TT 250pitch 4-array | GaAs/GaAs | 40G SR |
S-VS10TT1-000 |
VCSEL | 850 | 12*10/14G | 0 | TT 250pitch 12-array | GaAs/GaAs | 120G SR |
S-VS10TT1-001 |
VCSEL | 850 | 12*10/14G | 0 | TT 250pitch 12-array | GaAs/GaAs | 120G SR |
S-VS25ST1-000 |
VCSEL | 850 | 25G | 0 | TT Singlet | InGaAs/GaAs | 25G SR |
S-VS25FT1-000 |
VCSEL | 850 | 4*25G | 0 | TT 250pitch 4-array | InGaAs/GaAs | 100G SR |
S-VS28ST1-001 |
VCSEL | 850 | 100G | 0 | TT 250pitch 4-array | InGaAs/GaAs | 100G SR |
S-VS28FT1-001 |
VCSEL | 850 | 4*100G | 0 | TT 250pitch 4-array | InGaAs/GaAs | 400G SR |
S-DL10S27-000 |
DFB | 1270nm | 10G | 0 | Single | InGaAs/InP | BIDI |
S-DL10S33-000 |
DFB | 1330nm | 10G | 0 | Single | InGaAs/InP | BIDI |
S-DL25S27-C01 |
DFB | CWDM6 | 25G | 0 | Single | InGaAs/InP | CWDM |
S-DL25S29-C01 |
DFB | CWDM6 | 25G | 0 | Single | InGaAs/InP | CWDM |
S-DL25S31-C01 |
DFB | CWDM6 | 25G | 0 | Single | InGaAs/InP | CWDM |
S-DL25S33-C01 |
DFB | CWDM6 | 25G | 0 | Single | InGaAs/InP | CWDM |
S-DL25S73-L02 |
DFB | LWDM | 25G | 0 | Single | InGaAs/InP | LWDM |
S-DL25S77-L03 |
DFB | LWDM | 25G | 0 | Single | InGaAs/InP | LWDM |
S-DL25S82-L04 |
DFB | LWDM | 25G | 0 | Single | InGaAs/InP | LWDM |
S-DL25S86-L05 |
DFB | LWDM | 25G | 0 | Single | InGaAs/InP | LWDM |
S-DL25S95-L07 |
DFB | LWDM | 25G | 0 | Single | InGaAs/InP | LWDM |
S-DL25S00-L08 |
DFB | LWDM | 25G | 0 | Single | InGaAs/InP | LWDM |
S-DL25S04-L09 |
DFB | LWDM | 25G | 0 | Single | InGaAs/InP | LWDM |
