Sanan IC has a mature product portfolio of Silicon Carbide Schottky Barrier Diodes (SBDs). Utilizing an innovating merged PiN Schottky (MPS) structure and substrate thinning technology, the SiC SBD offers compelling price-performance while meeting the industry’s most stringent reliability requirements like HV-H3TRB. Built upon the 20-year foundation of Sanan Optoelectronics compound semiconductor excellence, Sanan IC delivers world class SiC SBD manufacturing with extremely low field failure rates. Leveraging a complete vertical integration (front- and back-end) and comprehensive online and reliability testing services, Sanan IC offers true “one-stop customer service solutions” to the power electronics industry.
Part Number
|
Type
|
Voltage (V)
|
IF (A)
|
Generation
|
VF@Tj=25℃ (V）
|
VF@Tj=175℃ (V）
|
IFSM@Tc=25℃ (A)
|
IR max@Tj=25℃ (uA）
|
Tj(℃)
|
Package
|
Qualification
|
|---|---|---|---|---|---|---|---|---|---|---|---|
|
SDS120J015H2
|
SBD | 1200 | 15 @Tc=150℃ | Gen-2 | 1.45 | 2 | 150 | 40 | -55~175 | TO247-2 | 工业级 |
|
SDS120J015C2
|
SBD | 1200 | 15 @Tc=150℃ | Gen-2 | 1.45 | 2 | 150 | 40 | -55~175 | TO220-2 | 工业级 |
|
SDS120J020H2
|
SBD | 1200 | 20 @Tc=146℃ | Gen-2 | 1.45 | 2.2 | 180 | 50 | -55~175 | TO247-2 | 工业级 |
|
SDS120J020C2
|
SBD | 1200 | 20 @Tc=146℃ | Gen-2 | 1.45 | 2.2 | 205 | 50 | -55~175 | TO220-2 | 工业级 |
|
SDS120J020G2
|
SBD | 1200 | 10/20 @Tc=150℃ | Gen-2 | 1.45 | 2.2 | 95* | 30 | -55~175 | TO247-3 | 工业级 |
|
SDS120J030G2
|
SBD | 1200 | 15/30 @Tc=144℃ | Gen-2 | 1.45 | 2 | 150* | 40 | -55~175 | TO247-3 | 工业级 |
|
SDS120J040G2
|
SBD | 1200 | 20/40 @Tc=142℃ | Gen-2 | 1.45 | 2.2 | 180* | 50 | -55~175 | TO247-3 | 工业级 |
|
SDS120J040H2
|
SBD | 1200 | 40 @Tc=135℃ | Gen-2 | 1.5 | 2.25 | 320 | 100 | -55~175 | TO247-2 | 工业级 |
|
SDS120J060A |
SBD | 1200 | 60 @Tc=121℃ | Gen-2 | 1.6 | 2.2 | 480 | 120 | -55~175 | SOT227 | 工业级 |
|
SDS120J080A |
SBD | 1200 | 80 @Tc=125℃ | Gen-2 | 1.55 | 2.1 | 640 | 160 | -55~175 | SOT227 | 工业级 |
|
SDS120J100A |
SBD | 1200 | 100 @Tc=138℃ | Gen-2 | 1.55 | 2.1 | 800 | 200 | -55~175 | SOT227 | 工业级 |
|
SDS065J004C3 |
SBD | 650 | 4 @Tc=150℃ | Gen-3 | 1.35 | 1.55 | 34 | 12 | -55~175 | TO220-2 | 工业级 |
|
SDS065J006C3 |
SBD | 650 | 6 @Tc=150℃ | Gen-3 | 1.3 | 1.55 | 54 | 18 | -55~175 | TO220-2 | 工业级 |
|
SDS065J008S3 |
SBD | 650 | 8 @Tc=150℃ | Gen-3 | 1.3 | 1.6 | 68 | 20 | -55~175 | DFN8*8 | 工业级 |
|
SDS065J008N3 |
SBD | 650 | 8 @Tc=150℃ | Gen-3 | 1.3 | 1.6 | 68 | 20 | -55~175 | TO220N-2 | 工业级 |
|
SDS065J008C3 |
SBD | 650 | 8 @Tc=150℃ | Gen-3 | 1.3 | 1.6 | 65 | 20 | -55~175 | TO220-2 | 工业级 |
|
SDS065J010S3 |
SBD | 650 | 10 @Tc=155℃ | Gen-3 | 1.3 | 1.6 | 80 | 20 | -55~175 | DFN8*8 | 工业级 |
|
SDS065J010C3 |
SBD | 650 | 10 @Tc=155℃ | Gen-3 | 1.25 | 1.45 | 80 | 20 | -55~175 | TO220-2 | 工业级 |
|
SDS065J012C3 |
SBD | 650 | 12 @Tc=150℃ | Gen-3 | 1.3 | 1.5 | 108 | 36 | -55~175 | TO220-2 | 工业级 |
|
SDS065J016C3 |
SBD | 650 | 16 @Tc=150℃ | Gen-3 | 1.3 | 1.55 | 135 | 48 | -55~175 | TO220-2 | 工业级 |
|
SDS065J020C3 |
SBD | 650 | 20 @TC=140℃ | Gen-3 | 1.35 | 1.55 | 140 | 60 | -55~175 | TO220-2 | 工业级 |
|
SDS120J020H3 |
SBD | 1200 | 20 @TC=140℃ | Gen-3 | 1.5 | 2.3 | 150 | 50 | -55~175 | TO247-2 | 工业级 |
|
SDS120J030H3 |
SBD | 1200 | 30 @Tc=137℃ | Gen-3 | 1.45 | 2.25 | 240 | 80 | -55~175 | TO247-2 | 工业级 |
|
SDS065J006S3 |
SBD | 650 | 6 @Tc=150℃ | Gen-3 | 1.3 | 1.55 | 48 | 18 | -55~175 | DFN8*8 | 工业级 |
|
SDS650J030G3 |
SBD | 650 | 15/30 @Tc=144℃ | Gen-3 | TO247-3 | 工业级 |
